Transspeed TK

Efficient deep-freeze solutions

Our Transspeed door is presented in its deep-freeze version - TK with a reinforced PVC curtain that is specially designed for use in deep-freeze environments. Frost resistance is guaranteed by an innovative heating system integrated into the tracks to ensure smooth functionality even in extreme temperatures.

In addition, automatic movement cycles every 20 minutes not only ensure increased functional reliability when opening and closing the door, but also provide protection against the mechanism freezing.

The permanent curtain tensioning system ensures that the door leaf is always under tension when opening and closing.
kept under tension when opening and closing.

Product Brochure

Technical details

Size range

Width (LDB) max.
4.000 mm
Height (LDH) max.
4.000 mm

Special dimensions on request

Drive speed

Frequency-controlled drive

Opening max.
2,0 m/s
Closing max.
0,8 m/s

Control unit

  • DR2100

Hanging

  •  available in various colors

Power rating

  • 230 V/50Hz, IP54 Drive

Do you need information material or do you have any questions or suggestions? We look forward to your call or message.
